| MOQ: | 1 Set |
| Price: | Negotiable |
| Standard Packaging: | Seaworthy packing |
| Delivery Period: | 50 Days |
| Payment Method: | L/C, T/T, Western Union |
| Supply Capacity: | 500 Tons / Month |
Water Wall Panels Description
The water cooling wall is the main radiant heating surface, which is arranged in the boiler box, and heat exchange is conducted directly with the high temperature flame.The convection pipe is the convection hot surface of the boiler. It is arranged between the outlet and the end surface of the boiler room.
Water-cooled walls and convection pipes are the main hot surfaces of boilers, and commonly used pipes are as wide as 51-60 mm boiler streel tubes, also as requested.
Specification
| Name | CFB hot water boiler ISO 9001 certification water wall panels |
| Material | Steel tubes |
| Tube size | φ 51-60 mm, or as required |
| Standard | ASME |
| Type | Studded |
| Series | 20 GB 3087; 20 GB 5310 |
| Equipment | Automatic production equipment |
| Application | Installated around the boiler combustion chamber |
Modern boilers use water-cooled wall panels to reduce heat loss due to air tightness and reduce insulation costs.We use automatic finned pipe welding machine and large pipe bending machine to make water-cooled wall plate to achieve the desired shape of the panel, can have short welding head.We provide panel integrated manhole openings in the panel.
The main function of boiler water wall board is to absorb the heat generated by high temperature flame or flue and to produce steam or hot water in the pipe, thus reducing the temperature in the box.
Advantage
1. The water cooling wall is the high-temperature radiant heat absorbed by the fuel chamber flame, which makes the water entering the water cooling wall evaporate into saturated steam.
2. Protect the furnace wall. The water cooling wall is laid on all sides to separate the combustion chamber from the furnace wall and prevent the furnace wall from being burnt out.
3. Simplify the furnace wall structure for easy installation, and pay attention to the anti-friction and explosion-proof network of the boiler.
4. The water-cooled wall tube can absorb radiation heat well, and its evaporation intensity is 4 times that of the convection tube bundle. Appropriately increasing the water-cooled wall tube in the furnace will reduce the number of convection and heating surface.
Workshop
Quality Control
1. Fabrication area of 200,000 square meters
2. 80 Engineers
3. 200 Coded welders
4. 30 Licensed Inspectors(NDT Level-III instructors)
5. Class-A Licenses for Design and Manufacture Boiler
6. ISO 9001:2015 Quality System
7. ASME Certificate of Power Boilers
8. ASME 'S','U' and NB stamp authorization
Company Indroduction
Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
