| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | Seaworthy packing |
| Delivery Period: | 30~50 days |
| Payment Method: | L/C, T/T, Western Union |
| Supply Capacity: | 500 tons per month |
Customized & Strict Produced Heat Recovery Steam Generator for Power Plant
Product Profile
Heat Recovery Steam Generator, refers to the use of various industrial process waste gas, waste or waste liquid waste heat and the heat was generated by the combustion of combustible substances to heat water to a certain temperature boiler.
Oil-fired boilers, gas-fired boilers and coal-fired boilers with smoke boxes and flue gas waste heat recovery are also called Heat Recovery Steam Generator. Heat Recovery Steam Generator can produce hot water or steam through waste heat recovery to supply other sections.
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
Features
Kiln (AQC) HRSG Features
1, Modular assembly structure, reliable sealing expansion
2, Adopt wear fin tubes, boiler pressure parts life assurance
3, Unique flash technology, the boiler outlet temperature is reduced to below 90ºC
Kiln (SP) HRSG Features
1, Heating surface tubes and headers with privildged connection structure, reducing mechanical shock and vibration
2, By mechanical vibration cleaning mode, continous cleaning mode little impact on system operation
3, Set sealed scraper gray machine, greatly reducing dust tail.
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
Advantages
Municipal solid waste incinerator(MSWI)
Straw burning boiler
Biomass Boilers
Waste heat recovery unit gas turbine
Low temperature HRSG boiler for dry cement kiln
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
Specifications
| Cement production line capacity t/d | 2500 | 3500 | 5000 | |
| Boiler inlet flow (Nm3/h) | Kiln(front) | 96800 | 142000 | 192000 |
| Kiln(tail) | 173000 | 241000 | 369000 | |
| Boiler inlet gas temperature℃ | Kiln(front) | 380 | 420 | 395 |
| Kiln(tail) | 365 | 360 | 355 | |
| Rated evaporation t/h | Kiln(front) | 2/9.6 | 3/17 | 3.2/21.3 |
| Kiln(tail) | 4.2/16.2 | 5.3/23 | 10.5/32 | |
| Rated steam pressure Mpa | Kiln(front) | 0.2/2.4 | 0.2/2.4 | 0.2/2.4 |
| Kiln(tail) | 0.2/2.4 | 0.2/2.4 | 0.2/2.4 | |
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
Company Information
☆ 1100 employees
☆400,000 ㎡ with fixed assets amounting to USD 110,000,000, 34 years experience
☆ISO9001, SO3834, EN12952 certificated
☆150km expressway to Shanghai,60km state road to Suzhou or Wuxi, this is how we keep superior quality and competitive offers for global valued customers.
★★★
Our main products cover Utility Boiler, HRSG Boiler, coal-fired , oil(gas) -fired, coal-water-slurry-fired and garbage-fired steam/hot water boilers, organic heat carrier boilers, etc., and Boiler spare parts (Economizer, Finned tube, Header, Steam drum, Superheater, Water wall panel, Air preheater, Cyclone separator, etc., which are widely used in power generation, heat supply, chemical engineering, textile, food, paper, road building, plastic, rubber and wood working industries.
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
Some Pictures
|
|
